ZL-8605

The working principle of the pressure reducing valve is to change the speed and pressure of the fluid through the valve by adjusting the passage area of the fluid. When the pressure in the system exceeds the set pressure range, the pressure reducing valve will automatically open, allowing a part of the fluid to flow out, thereby reducing the pressure of the system. Conversely, when the pressure of the system is lower than the set value, the pressure reducing valve will close to prevent the fluid from continuing to flow out, thereby maintaining the stability of the system.

Pressure reducing valve can be divided into direct and indirect two types. Direct type pressure reducing valve is the pressure reducing valve and regulating valve into one design, by adjusting the tension of the spring to achieve the adjustment of the fluid pressure. The indirect pressure reducing valve is divided into two parts: the main pressure reducing valve and the auxiliary pressure reducing valve. The main pressure reducing valve is responsible for receiving high-pressure fluid and making preliminary adjustment, while the auxiliary pressure reducing valve makes fine adjustment to the main pressure reducing valve to achieve more accurate pressure control.

In the industrial field, pressure reducing valve is usually used in water treatment, petrochemical, pharmaceutical, fertilizer, electric power and other industries. For example, a pressure reducing valve can be used to reduce the pressure of a high-pressure water source to a suitable pressure to ensure the normal operation of the equipment and the safety of water. In civil facilities, pressure reducing valves are also widely used in building water systems, HVAC systems, etc., to protect system equipment and pipelines from high pressure hazards.

Valve in practical applications need to consider a variety of factors, such as flow, pressure, medium and temperature. Different working conditions and requirements may require the selection of different types and specifications of the pressure reducing valve. Therefore, the choice of suitable pressure reducing valve needs to consider the specific situation and needs of the system, and refer to the relevant technical parameters and standards.

In short, the pressure reducing valve is an important fluid control device that can effectively protect system equipment and pipelines from excessive pressure damage. Pressure reducing valve is widely used in the industrial field and civil facilities, and plays an important role in ensuring the safe and reliable operation of the system.

Material: Brass hpb57-3

Normal pressure: ≤ 10bar

Applicable medium: hot and cold water

Operating temperature: t≤ 110°C

Connection thread: ISO228 standard

Specifications 3/8   1/2   3/4    1
